Bottled Water Dispenser

SPECIAL FEATURES
Float switch for automatic shut off when bottle is empty
Built-in check valve to prevent back flow
Universal seal cap fits most water containers
Compact size for easy mounting
20"discharge hose include
Easily Installed.

Water Dispenser
Bottled Water Dispenser

Model NO.:BWD1200, 600



Max.Head:<10m

Max.Capacity:<50 L/min



Driving Type:Motor

Material:Plastic



Structure:Diaphragm Pump

Assembly:Liquid Pumps



Power:Electric

Start Up:Electric Pump



Type:Diaphragm Pump

Application:Clarified Water Pump, Coffee Pump



Industry:Food Pumps

Media:Water, Coffee,Juice



Performance:No Leakage Pump

Theory:Reciprocating Pump



Noise Level:40-60dba

Voltage:115/230V,AC,12VDC



Features: Compact Size for Easy Mounting

Standard Hose:6 Meters 1/4"



Connect Fitting:1/4" & 3/8"



Specification:CE


Feature:
1.Easiest way to connect this to your filtration kit/espresso machine
2.Float switch for auto shut-off when bottle is empty
3.Built-in check valve to prevent back flow
4.Universal seal cap fits most water containers
5. Compact size for easy mounting
6.Long Life Motor: Ensures years of reliable operation
7.Easy installed


Specifications:
Max. Flow Rate: 1.0 gpm (3.8 lpm)
Max. Pressure: 40 psi (2.8 bar)
Dimensions: 3.0 H x 5.5 W x 7.5 D inches (7.6 x 14.0 x 19.0 cm)
Voltage 115 or 230 V AC 12 V DC
Amp Draw: 12 Volt 3.0 Amps. Max.
115 Volt   0.5 Amps. Max.
230 Volt   0.25 Amps. Max.
Cycles: AC models 50/60 Hz
Weight: 2.9 kg(5.6 net lbs)



Bottled Water Dispenser
Bottled Water Dispenser

Product Name: Water Dispenser Pump CYD-2

• Switch: Button

• Rated Voltage: 5V

• Rated Power: 5W

• Battery: 1000mA

• Material: ABS plastic

• Silicone tube: Food Grade

• Net weight: 309g

• Packing Size: 51*37*51cm

• Certificate: CE & Rohs

• Color: Blue/ White

• Accessories: Silicone tube, Wireless water

pump, USB cable, Operation instructions

Water Dispenser Thailand

Product Name: Water Dispenser Pump CYD- 6

• Switch: Touch

• Rated Voltage: 5V

• Rated Power: 5W

• Battery: 1000mA

• Material: ABS plastic

• Silicone tube: Food Grade

• Net weight: 303g

• Packing Size: 51*37*51cm

• Certificate: CE & Rohs

• Color: Black/ White

• Accessories: Silicone tube, Wireless water

pump, USB cable, Operation instructions

Water Dispenser Thailand
